Cantilevered Vault Collection
Maximum Covered Space.
Minimum Structural Intervention.
The MECANCO Cantilevered Barrel Vault Series is built around one defining principle — delivering maximum covered space with minimum structural intervention.
By engineering the roofing load into a cantilever, these structures eliminate the need for support columns within the usable zone entirely — creating obstruction-free, freely flowing spaces beneath a single-sloped or arched tensile membrane profile.
Whether wall-mounted, single-side column-mounted, suspended on overhang supports or reinforced through under-truss and inclined support systems — every configuration is engineered to push the membrane outward, over and beyond, without compromise to the space it protects.
The result is a roofing system that combines structural efficiency, architectural lightness and uninterrupted functionality within one highly refined engineering solution.
Reach further, cover more, obstruct nothing —
the cantilever, made architectural.
Cantilevered Barrel Vault Range
Engineered Configurations.
Adapted To Every Site Condition.
The MECANCO Cantilevered Barrel Vault Range is offered across a versatile series of structural configurations and edge treatments — each engineered to respond precisely to the spatial, structural and architectural demands of the site.
Cantilever Capacity
Extended Reach.
Engineered Without Compromise.
MECANCO’s standard cantilevered barrel vault engineering supports cantilever projections of up to 6 meters — comfortably covering a wide range of functional and architectural applications within this range.
The structural system is engineered to maintain stability, visual lightness and uninterrupted usability beneath the canopy, ensuring maximum covered area with minimal structural intrusion.
For projects demanding greater reach, fully customised engineering solutions are developed beyond the standard 6-meter capacity — carefully resolved on a site-specific basis according to span, loading conditions, usage requirements and architectural intent.
This flexibility allows the MECANCO cantilever system to adapt seamlessly from compact functional shelters to ambitious large-scale architectural canopy structures.
Applications & Utility
Designed To Adapt.
Engineered To Perform Everywhere.
The MECANCO Cantilevered Barrel Vault Series is among the company’s most versatile and widely specified product lines — a direct reflection of how universally the cantilever principle adapts across architectural, commercial and landscape environments.
By eliminating intrusive support columns within the usable space, the system creates clean, uninterrupted covered environments that combine functionality, openness and architectural lightness.
Materials
Material Options For
Every Performance Requirement
The series accommodates a range of membrane materials to suit the functional and aesthetic requirements of each application — ensuring the right performance specification for every environment.
